CNC Vertical Rotary Surface Grinder

Get a Price/Quote

Product Details:

Table Size 800 mm Diameter
Features High Precision, Rigid Structure
Machine Type Rotary Surface Grinder
Motor Power 7.5 HP
Dimension (L*W*H) 2500 x 1800 x 2100 mm
Cutting Area 800X350 mm
Diameter 800 mm
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

CNC Vertical Rotary Surface Grinder Price And Quantity

Minimum Order Quantity 1 , , Piece

CNC Vertical Rotary Surface Grinder Product Specifications

Control System PLC Based
Power Source Electric
Computerized Yes
Capacity 800X350 mm
Table Size 800 mm Diameter
Machine Type Rotary Surface Grinder
Usage & Applications Metal Surface Grinding
Features High Precision, Rigid Structure
Power 7.5 kW (Approx)
Motor Power 7.5 HP
Dimension (L*W*H) 2500 x 1800 x 2100 mm
Voltage 220 - 380 V
Automatic Grade Automatic
Weight (kg) 3200 kg (Approx)
CNC Or Not CNC
Diameter 800 mm
Color Blue / White / Green
Cutting Area 800X350 mm
Condition New
Noise Level Low
Product Type CNC Vertical Rotary Surface Grinder
Material Stainless Steel / Mild Steel
Spindle Speed 1800 rpm (Approx)
Frequency 50 - 60 Hz

Work Holding Magnetic Chuck
Phase Three Phase
Grinding Wheel Resin Bonded
PLC Display Touch Screen Interface
Table Drive Servo Motor
Vertical Axis Automatic Feed
Safety Overload Protection
Lubrication Centralized Automatic
Coolant System Integral

CNC Vertical Rotary Surface Grinder Trade Information

Supply Ability 1 , , Piece Per Day
Delivery Time 1 Days

Product Description

Utilise this Hot Deal and seize the opportunity to own a first-string CNC Vertical Rotary Surface Grinder, a formidable and breathtaking machine engineered for exquisite metal surface grinding. Featuring an intuitive PLC touch screen interface, servo-driven table, and centralized automatic lubrication, this value-driven grinder delivers uncompromised high precision and a rigid structure, all in an automatic, computerized package. Supplied with an integral coolant system, magnetic work holding, and overload protection for safety, this premium-grade grinder is ideal for stainless steel and mild steel applications. Available in blue, white, or green-exported and supplied across India.

Versatile Operation: Directions, Applications & Utility

To utilise this state-of-the-art CNC Vertical Rotary Surface Grinder, simply set your metal workpiece on the magnetic chuck and program your grinding parameters using the touch screen PLC interface. Its formidable features make it ideal for high-precision grinding of stainless steel and mild steel components. The machine finds extensive usage in tool rooms, production lines, and heavy-duty workshops, crafting flat, smooth metal surfaces efficiently. Additional applications include die making, industrial component preparation, and repair engineering.

Supply, Expenditure & Logistics Details

Supply for the CNC Vertical Rotary Surface Grinder is maintained through robust logistics networks ensuring timely delivery within India and for export. Combining exceptional value with economical expenditure, units are shipped from our primary FOB port as per client schedule. We accommodate flexible payment terms, including LC, TT, and negotiable options, allowing manufacturers, suppliers, and traders to procure with confidence and efficient budget management.

FAQ's of CNC Vertical Rotary Surface Grinder:

Q: How does the automatic feed contribute to the grinding process?

A: The automatic feed on the vertical axis ensures consistent, precise material removal, enhancing surface finish quality while minimizing manual intervention and boosting overall productivity.

Q: What materials can be processed with this CNC rotary surface grinder?

A: This grinder is designed to handle both stainless steel and mild steel, making it suitable for a range of industrial metal grinding applications.

Q: When should I utilise overload protection features?

A: Overload protection is crucial during intense grinding operations to prevent machine damage or failure, ensuring reliable performance and long-term durability.

Q: Where can this machine be effectively utilised?

A: The CNC Vertical Rotary Surface Grinder excels in manufacturing plants, tool rooms, maintenance workshops, and production lines requiring flawless metal surface finishing.

Q: What are the key benefits of a PLC-based control system with a touch screen interface?

A: A PLC-based control system combined with a touch screen interface streamlines operation, offers greater programming flexibility, user-friendly controls, and reduces setup time, resulting in enhanced accuracy and efficiency.
