Cage Welding Machine
6500000 INR/Piece
Product Details:
- Pulse Frequency Adjustable as per Requirement
- Efficiency High Efficiency, Continuous Operation
- Condition New
- Input Current 30-40 A (Approx.)
- Output Current Adjustable as Required
- Dimension (L*W*H) Approx. 8000 x 2000 x 2200 mm
- Weight 4000-6000 kg (Depends on configuration)
- Click to View more
X
Cage Welding Machine Price And Quantity
- 6500000 INR/Piece
- 1 Piece
Cage Welding Machine Product Specifications
- 50/60 Hz
- 4 mm - 16 mm
- Water Cooling
- F
- Automatic Welding of Reinforcing Cages
- 380-415 V
- Cage Welding Machine
- AC Electric Motor
- 12-15 kW
- High Efficiency, Continuous Operation
- Adjustable as per Requirement
- New
- Automatic Cage Assembly
- Construction, Precast, Infrastructure Industries
- 30-40 A (Approx.)
- Approx. 8000 x 2000 x 2200 mm
- 4000-6000 kg (Depends on configuration)
- Mild Steel/Alloy Steel
- Adjustable as Required
- Automatic, As Per Welding Cycle
- Powder coated/painted frames
- 150-300 cages per shift (depending on specifications)
- Automatic and programmable
- Suitable for precast, foundation, pile, column cages
- PLC Controlled with HMI Interface
- Multiple heads for simultaneous welding
- Emergency stop, overload protection, safe guarding
- Servo/Chain drive
- 3 Phase
- 75 dB
- 5C - 45C
- Fully / Semi Automatic options
- Up to 1200mm/min
Cage Welding Machine Trade Information
- 1 Piece Per Day
- 1 Days
Product Description
This high performance Cage Welding Machine combines a number of advanced features for its high output. This machine is used to weld metal wire made cages meant for poultry. This high performance machine comprises of pneumatic electrodes to improve its operating speed. All the components of this system belong to renowned brands for its optimum productivity. PLC based mechanism of this Cage Welding Machine is effective in adjusting welding current. Precise operation, utilization of energy efficient servo motor and automatic mesh cutting arrangement are some of its important aspects.
Technical Specification
|
Voltage |
220 - 360 V |
|
Frequency |
50 - 60 Hz |
|
Brand |
Velocity |
|
Automation Grade |
Automatic |
|
Usage/Application |
Commercial |
|
Material |
Mild Steel |
High-Efficiency Automated Cage Production
This machine streamlines the fabrication of reinforcing cages by integrating automatic wire feeding, servo-controlled welding, and continuous operation. Its PLC-based control system and advanced resistance spot welding technology enable consistent, high-speed output with minimal manual intervention. Designed for demanding construction, precast, and infrastructure projects, it helps boost productivity and reduces operational labor demands.
Advanced Safety and Reliability
Operator safety is ensured through an interlocking protection system that prevents hazardous situations. The water-cooled system maintains optimal machine temperature, supporting high duty cycles and prolonging equipment lifespan. The robust construction using mild steel or alloy steel guarantees durability for heavy-duty applications.
FAQ's of Cage Welding Machine:
Q: How does the PLC control system enhance the operation of the cage welding machine?
A: The programmable logic controller (PLC) streamlines the machine's operation by automating sequence control, monitoring system parameters, and simplifying adjustments for welding cycles, wire feeding, and speed. This results in higher efficiency, precise repeatability, and easier customization for specific production requirements.Q: What types of reinforcing cages can be manufactured with this cage welding machine?
A: This machine is suitable for producing pile cages, column cages, beam cages, and tunnel segments. Its adjustable settings and robust construction make it ideal for a range of construction and infrastructure applications.Q: When should the welding speed be adjusted and how does it affect production?
A: Welding speed can be varied to match different project specifications, material thickness, or desired quality. Adjusting speed ensures optimal weld strength and productivity for each specific application, enhancing output without compromising result integrity.Q: Where is the cage welding machine typically used?
A: It is widely utilized in facilities manufacturing components for the construction, precast, and larger infrastructure industries. Common deployment sites include factories producing reinforcing cages for foundations, columns, and tunnels.Q: What is the process flow for automatic cage assembly using this machine?
A: The process starts with automatic wire feeding, followed by precise spot welding as directed by the PLC and servo-controlled head movement. The cage is formed and assembled automatically, requiring supervision by only one or two operators.Q: What safety features are integrated into the machine?
A: The interlocking protection system is a key safety component, preventing access to hazardous areas during operation. This, combined with low noise levels and managed cooling, promotes a safer, more comfortable working environment.Q: What are the main benefits of using a PLC-controlled cage welding machine in construction projects?
A: Major benefits include significant labor savings, consistent weld quality, increased production rates, higher operational safety, reduced error rates, and the ability to customize cages for diverse construction needs, leading to overall improved project efficiency.Tell us about your requirement
